Product Summary
The BLF574 is a HF / VHF power LDMOS transistor. It is suitable for broadcast applications and industrial applications in the HF to 500 MHz band.
Parametrics
Absolute maximum ratings: (1)VDS, drain-source voltage: 110 V max; (2)VGS, gate-source voltage: -0.5 to +11 V; (3)ID, drain current: - 56 A max; (4)Tstg, storage temperature: -65 to +150 ℃; (5)Tj, junction temperature: 225 ℃ max.
Features
Features: (1)Easy power control; (2)Integrated ESD protection; (3)Excellent ruggedness; (4)High efficiency; (5)Excellent thermal stability; (6)Designed for broadband operation (10 MHz to 500 MHz); (7)Compliant to Directive 2002/95/EC, regarding Restriction of Hazardous Substances (RoHS).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BLF574 |
NXP Semiconductors |
Transistors RF MOSFET Power 500-600W, HF-500MHz |
Data Sheet |
Negotiable |
|
||||||||
 |
BLF574,112 |
NXP Semiconductors |
Transistors RF MOSFET Power Trans MOSFET N-CH 110V 42A 5-Pin |
Data Sheet |
|
|
||||||||
